PESS56C1M-4-RB - NORTH AMERICAN

(0)No Reviews yet
$552.29

Details

Details

MaterialCast Iron
Full Load RPM1800.0
RPM1800.0
Frame56C
Full Load Amps at Rated Voltage2.7
Frequency Hz60.0
Voltage208/230/460 VAC|208 VAC|230 VAC|460 VAC|230/460 VAC
Full Load Efficiency Percentage85.5
Service Factor1.15
Insulation ClassF
NEMA DesignB
NEMA CodeK
Locked Rotor Amps at Rated Voltage15.0
Power Factor71.0
Drive End Bottom Bearing6205-2RS
Opposite Drive End Upper Bearing6205-ZZ
Drive End Upper Bearing6205-ZZ
Opposite Drive End Bottom Bearing6205-ZZ
Inverter Rated or DutyInverter Duty
PhaseThree Phase
Model NumberPESS56C1M-4-RB
Weight (lbs)35.0
ApplicationWashdown Duty
HP Range1.0
HP1.0
GTIN192999024379
Enclosure Height Inch7.1
Enclosure Height MM180.34
Enclosure Length Inch14.6
Enclosure Length MM370.84
Motor Enclosure TypeTotally Enclosed|TEFC
RPM Range1800.0

UNIT PRICE:

$552.29



UNIT PRICE:

SPECIFICATIONS

MaterialCast Iron
Full Load RPM1800.0
RPM1800.0
Frame56C
Full Load Amps at Rated Voltage2.7
Frequency Hz60.0
Voltage208/230/460 VAC|208 VAC|230 VAC|460 VAC|230/460 VAC
Full Load Efficiency Percentage85.5
Service Factor1.15
Insulation ClassF
NEMA DesignB
NEMA CodeK
Locked Rotor Amps at Rated Voltage15.0
Power Factor71.0
Drive End Bottom Bearing6205-2RS
Opposite Drive End Upper Bearing6205-ZZ
Drive End Upper Bearing6205-ZZ
Opposite Drive End Bottom Bearing6205-ZZ
Inverter Rated or DutyInverter Duty
PhaseThree Phase
Model NumberPESS56C1M-4-RB
Weight (lbs)35.0
ApplicationWashdown Duty
HP Range1.0
HP1.0
GTIN192999024379
Enclosure Height Inch7.1
Enclosure Height MM180.34
Enclosure Length Inch14.6
Enclosure Length MM370.84
Motor Enclosure TypeTotally Enclosed|TEFC
RPM Range1800.0
