60B24 - B & B MANUFACTURING
- Teeth: 24
- Tooth Style: 60
- Type: B
- Bore Type: Minimum Plain Bore
SPECIFICATIONS
| Teeth | 24 |
|---|---|
| Tooth Style | 60 |
| Type | B |
| Bore Type | Minimum Plain Bore |
| Pitch Diameter Inch | 5.746 |
| Outer Diameter Inch | 6.147 |
| Bore / Inner Diameter Inch | 0.75 |
| Minimum Bore Inch | 0.750 |
| Face Width Inch | 0.459 |
| Overall Length Inch | 1.25 |
| Hub Diameter Inch | 4 |
| Pitch Diameter MM | 145.948 |
| Outer Diameter MM | 156.134 |
| Bore / Inner Diameter MM | 19.05 |
| Face Width MM | 11.659 |
| Overall Length MM | 31.75 |
| Hub Diameter MM | 101.6 |
| Material | Steel |
