40B112 - B & B MANUFACTURING
- Teeth: 112
- Tooth Style: 40
- Type: B
- Bore Type: Minimum Plain Bore
SPECIFICATIONS
| Teeth | 112 |
|---|---|
| Tooth Style | 40 |
| Type | B |
| Bore Type | Minimum Plain Bore |
| Pitch Diameter Inch | 17.828 |
| Outer Diameter Inch | 18.121 |
| Bore / Inner Diameter Inch | 1 |
| Minimum Bore Inch | 1.000 |
| Face Width Inch | 0.284 |
| Overall Length Inch | 1.25 |
| Hub Diameter Inch | 4 |
| Pitch Diameter MM | 452.831 |
| Outer Diameter MM | 460.273 |
| Bore / Inner Diameter MM | 25.4 |
| Face Width MM | 7.214 |
| Overall Length MM | 31.75 |
| Hub Diameter MM | 101.6 |
| Material | Steel |
