4/3V670 - D&D GLOBAL
4/3V670 V Belts , Width Inch:1.52, Upper Width Per Section Inch:0.375, Height Inch:0.328125
SPECIFICATIONS
| Intended Pulley Angle | 0.32 |
|---|---|
| Number of Ribs | 4 |
| Type | 3V |
| Belt Width Inch | 1.52 |
| Series | Dura-Prime Wedge |
| Upper Width Per Section Inch | 0.375 |
| Weight (lbs) | 1.5 |
| Outside Belt Diameter Inch | 67.0 |
| Outside Belt Diameter MM | 1701.8 |
| Belt Thickness / Sidewall Depth Inch | 0.328 |
| Belt Thickness / Sidewall Depth MM | 8.33 |
