35B45 - B & B MANUFACTURING
- Teeth: 45
- Tooth Style: 35
- Type: B
- Bore Type: Minimum Plain Bore
SPECIFICATIONS
| Teeth | 45 |
|---|---|
| Tooth Style | 35 |
| Type | B |
| Bore Type | Minimum Plain Bore |
| Pitch Diameter Inch | 5.376 |
| Outer Diameter Inch | 5.588 |
| Bore / Inner Diameter Inch | 0.625 |
| Minimum Bore Inch | 0.625 |
| Face Width Inch | 0.168 |
| Overall Length Inch | 1 |
| Hub Diameter Inch | 2.25 |
| Pitch Diameter MM | 136.55 |
| Outer Diameter MM | 141.935 |
| Bore / Inner Diameter MM | 15.875 |
| Face Width MM | 4.267 |
| Overall Length MM | 25.4 |
| Hub Diameter MM | 57.15 |
| Material | Steel |
