100B11-IDLER - B & B MANUFACTURING
- Teeth: 11
- Tooth Style: 100
- Type: B
- Bore Type: Idler
SPECIFICATIONS
| Teeth | 11 |
|---|---|
| Tooth Style | 100 |
| Type | B |
| Bore Type | Idler |
| Pitch Diameter Inch | 4.177 |
| Outer Diameter Inch | 5.01 |
| Bore / Inner Diameter Inch | 1.5 |
| Face Width Inch | 1.875 |
| Overall Length Inch | 1.875 |
| Pitch Diameter MM | 106.096 |
| Outer Diameter MM | 127.254 |
| Bore / Inner Diameter MM | 38.1 |
| Face Width MM | 47.625 |
| Overall Length MM | 47.625 |
| Material | Steel |
| Finish | Black Oxide |
