FYTB 25 TF - SKF
- Bore / Inner Diameter Inch: 0.984
- Bore / Inner Diameter MM: 25
- Number of Mounting Holes: 2
- Bolt Center to Center Inch: 3.9
- Bolt Center to Center MM: 99
- Bearing Locking Style: Set Screw
SPECIFICATIONS
| Bore / Inner Diameter Inch | 0.984 |
|---|---|
| Bore / Inner Diameter MM | 25 |
| Number of Mounting Holes | 2 |
| Bolt Center to Center Inch | 3.9 |
| Bolt Center to Center MM | 99 |
| Bearing Locking Style | Set Screw |
| Rolling Element | Ball Bearing |
| Housing Material | Cast Iron |
| Housing Style | 2 Bolt Flange Block |
| Expansion / Non-Expansion | Non-expansion |
| Length Across Bore Inch | 1.343 |
| Length Across Bore MM | 34.1 |
