367L050 - GATES
367L050 Synchronous Belts , Width Inch:0.5, Height Inch:.140
SPECIFICATIONS
| Belt Width Inch | 0.50 |
|---|---|
| Belt Width MM | 12.7 |
| Timing Belt Pitch Inch | 0.375 |
| Timing Belt Pitch MM | 9.5 |
| Outside Belt Diameter Inch | 36.75 |
| Outside Belt Diameter MM | 933.4 |
| Number of Teeth | 98 |
| Belt Thickness / Sidewall Depth Inch | 0.14 |
| Belt Thickness / Sidewall Depth MM | 3.6 |
| GTIN | 840593145869 |
| Model Number | 367L050 |
